M68MM16 Micromodule 16 Memory-I/O-Timer Expansion ModuleΒΆ

../../../../_images/M68MM16.1.png
../../../../_images/M68MM16.2.png
../../../../_images/M68MM16.3.png
../../../../_images/M68MM16.4.png

Note

There are three versions of the M68MM16 Micromodule:

M68MM16-1, 2, 3

This module provides functional expansion of Monoboard MM01 (version 16-1), or MM19 (version 16-2), and can be used as MM19 Emulator in an EXORset Development System (version 16-3). Includes asynchronous serial data port with strap-selectable RS-232C, RS-422, or RS-423 interface, parallel control lines, three 16-bit programmable counter/timers, and four sockets for user installed, single 5-volt-supply MOS or bipolar memories.
